Why Choose the Aomway Commander V2?

The Aomway Commander V2 sets a new standard for FPV goggle performance at its price point. Designed by pilots for pilots, every feature is engineered to give you the competitive edge — whether you're racing, freestyling, or running long-range missions.

Display & Optics

Dual high-resolution LCOS microdisplays deliver pin-sharp 854×480 resolution with a wide, immersive field of view. Colors are vibrant and blacks are deep — no washed-out image here. The adjustable IPD (56–72mm) and focal correction lenses (±6 diopter) ensure a perfect fit for nearly every pilot.

Resolution: 854×480 (WVGA) per eye
FOV: Wide immersive viewing angle
Display Type: LCOS (Liquid Crystal on Silicon)
IPD Range: 56–72 mm adjustable
Focal Adjustment: ±6 diopter support

Receiver & Video System

At the heart of the Commander V2 is an integrated diversity receiver with two independent tuner modules. The system constantly monitors signal strength across both antenna paths and seamlessly switches to the strongest feed — no glitching, no breakup. Supports all major FPV bands including Raceband, covering 5.8GHz with 48 channels.

Receiver: Integrated dual-antenna diversity
Frequency: 5.8GHz, 48 channels (all standard bands + Raceband)
Antenna Connectors: Dual SMA (RP-SMA compatible)
Built-in DVR: Micro SD card slot, records H.264 at full resolution
Latency: Ultra-low glass-to-glass

Connectivity & Expandability

The Commander V2 isn't just a goggle — it's a cockpit. An HDMI input port lets you connect ground stations, flight simulators, or any external HDMI source. The dedicated 3.5mm AV input accepts analog video from legacy gear. A removable head tracker module bay gives you room to add your own tracking system for antenna tracking setups.

HDMI In: Full-size HDMI port
AV In: 3.5mm jack
Audio: Built-in speaker + 3.5mm headphone jack
Head Tracker Bay: Removable for third-party modules
Firmware: User-upgradeable via USB

Power & Battery

Wide voltage support from 2S to 6S LiPo means you can power the Commander V2 directly from nearly any battery in your kit. The integrated low-voltage alarm warns you long before the goggle dies, and each pack delivers 4–6 hours of continuous flight time depending on battery capacity.

Input Voltage: DC 7–25.2V (2S–6S LiPo)
Power Consumption: ~5W typical
Battery Connector: XT60 (cable included)
Runtime: 4–6 hours on a standard 2S 2000mAh pack

Comfort & Build Quality

Weighing just 260 grams, the Commander V2 is one of the lightest full-featured goggles in its class. The ergonomic faceplate uses a triple-layer foam padding that conforms to your face shape. A built-in cooling fan circulates air across the lens cavity to prevent fogging — even in tropical humidity. The adjustable head strap distributes weight evenly for fatigue-free multi-hour sessions.

Weight: ~260g (without battery)
Faceplate: Triple-layer memory foam
Anti-Fog: Forced-air fan system
Head Strap: 3-point adjustable with quick-release

What's in the Box

Aomway Commander V2 FPV Goggle ×1
Dual 5.8GHz antenna set ×1
XT60 power cable ×1
USB firmware update cable ×1
Microfiber lens cleaning cloth ×1
Carrying case ×1
User manual ×1

Who Is It For?

The Commander V2 is ideal for intermediate to advanced FPV pilots who want top-tier features — diversity receiver, DVR recording, HDMI input, wide-voltage power — without paying flagship prices. It's equally at home on the race course, in the freestyle park, or on a long-range mountain run. If you've outgrown your box goggles and want a real upgrade, the Commander V2 is your next step.

At just $500, it delivers a feature set that competes with goggles costing twice as much. Backed by Aomway's quality engineering and a global community of pilots, this is the goggle that grows with you.

Buy Aomway Commander V2 — $500
