Why Choose the Aomway 5.8G 10W Power Video Transmitter?

When your UAV or FPV application demands uncompromising video link reliability at extreme ranges, the Aomway 5.8G 10W video transmitter delivers. With 10 watts of output power — far beyond typical 600mW or 1W VTX modules — this transmitter punches through signal obstacles, buildings, and terrain to maintain a clear video feed where conventional transmitters fail.

Built for professional and industrial use, the Aomway 5.8G 10W VTX offers wide frequency flexibility, active thermal management, and robust CNC construction that stands up to field conditions.

Key Features

10W Output Power — Industry-leading transmission power provides exceptional range and penetration through obstacles, buildings, and dense vegetation
Wide Frequency Coverage — 4900–6200MHz standard range with IRC protocol (1MHz step); custom frequencies from 1GHz to 9GHz available with zero setup fee
Active Cooling System — 6015 cooling fan combined with aluminum heatsink enables sustained high-power operation without thermal throttling
CNC Aluminum Housing — Precision-machined chassis with digital channel display for at-a-glance status monitoring
SMA Female Connector — Standard RF interface compatible with a wide range of antenna options
Compact Form Factor — 7 × 4 × 3 cm, 0.2 kg — easily integrated into existing UAV payload bays
Customizable Frequency — Any frequency between 1GHz and 9GHz available on request with no additional engineering charges

Technical Specifications

Frequency Range	4900–6200MHz (standard) / 1–9GHz (custom)
Output Power	10W
Protocol	IRC (1MHz step)
Cooling	Active fan (6015) + aluminum heatsink
Connector	SMA female
Housing	CNC aluminum with digital display
Weight	0.2 kg
Dimensions	7 × 4 × 3 cm
